Blum Inserta Drilling Gauge

The Blum Inserta Drilling Gauge is a simple device used to drill holes for INSERTA style hinges and system screw holes for wing-type mounting plates. For details click on the installation tab below.

Simple product items
Item Number Description Color UOM Base Price Base Price
(Qty)
Volume Pricing Qty
B065.059A

Drilling gauge

Blum Inserta Drilling Gauge
EA
$45.70
  • Hinge drilling steps:
  • 1. Determine hinge position
  • 2. Drill 35mm hole using drill press
  • 3. Adjust drilling distance by turning drilling distance selector
  • 4. Position drilling gauge (drilling distance selector facing down)
  • 5. Drill 8mm holes
  • Wing mounting plate drilling steps:
  • 1. Determine mounting plate position
  • 2 Position drilling gauge (drilling distand, selector facing up)
  • 3. Drill 5mm holes for mounting with system screws mark pilot holes for wood screws with a center punch
Specification
Color Orange
Manufacturer Blum
Type Jigs
Shipping : All orders are shipped in 24 hours
